50W 698-6000MHz 2 Way Microstrip RF Power Splitter with DIN-Female Connector Ibs Bts Das Ready
Product Details:
| Place of Origin: | China |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Piece |
|---|---|
| Delivery Time: | Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays |
| Payment Terms: | LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram |
|
Detail Information |
|||
| Model NO.: | GFQ-XXXXXX | RF Connector: | 4.3-10 F/N-F/DIN-F |
|---|---|---|---|
| Color: | Black | Applications: | Indoor/Outdoor |
| Transport Package: | Carton/Palletizing | Specification: | See Below Data Table |
| Trademark: | BF TECH | Origin: | China |
| Supply Ability: | 2000000PCS/Year | Package Size: | 22.00cm * 7.00cm * 4.00cm |
| Package Gross Weight: | 0.510kg | ||
Product Description
- Wide frequency band, wide coverage.
- PIM optimized design.
- Ideal for all kind of DAS applications.
- Low insertion loss.
- High power handling.
- Small size, Low weight.
- Good stability.
| PN.(X is) | 2 |
| Frequency Range(MHz) | 698-6000 |
| Type | 2 /3/4Way |
| Insertion Loss(dB) | ≤ 3.4 |
| VSWR | ≤ 1.3 |
| PIM3 (dBc@2*43dBm) | ≤ -160 |
| Input Power(W) | 300 |
| Impedance(Ω) | 50 |
| RF Connector | 4.3-10 F/N-F/DIN-F |
| Color | Black |
| Relative humidity | 5%~95% |
| Operating Temperature(°C) | -35 ~ +75 |
| Applications | Indoor/Outdoor(IP65) |
