2.92mm Female to 2.92mm K Female Adapter RF Connector Compact and for Easy Integration
Product Details:
Get Best Price Contact Now
Detail Information |
|||
Model NO.: | LJQ -XXXXX | Insertion Loss (dB): | 0.25 |
---|---|---|---|
Pim: | -155dbc | Durability: | More Than 500 Cycles |
Waterproof Rate: | IP 67 | RoHS Compliant: | Full RoHS Compliance |
Transport Package: | Carton/Palletizing | Specification: | See Below Data Table |
Trademark: | BF TECH | Origin: | China |
Supply Ability: | 2000000PCS/Year | Package Size: | 8.00cm * 5.00cm * 5.00cm |
Package Gross Weight: | 0.210kg |
Product Description
★Wide frequency band, wide coverage.
★PIM optimized design.
★Ideal for all kind of IBS/DAS/PDAS applications.
★Low insertion loss.
★High power handling.
★Small size, Low weight.
★Good stability.
Specifications:
Electrical | ||||
Characteristic Impedance | 50 ohm | |||
Frequency Range | DC-4GHz | |||
VSWR | ≤1.2 | |||
PIM | ≤-155dBc | |||
Insertion Loss | ≤0.25dB | |||
Dielectric Withstanding Voltage | ≥2500V RMS,50hz,at sea level | |||
Working Voltage | ≤1000V RMS,50Hz,at sea level | |||
Dielectric Resistance | ≥5000MΩ | |||
Contact Resistance | Center Contact | ≤0.4mΩ | ||
Outer Contact | ≤0.4mΩ | |||
Environmental & Mechanical | ||||
Temperature Range | -45ºC ~ +85ºC | |||
Waterproof Rate | IP 67 | |||
Durability | ≥500 cycles | |||
ROHS compliant | Full ROHS compliance | |||
Material and Plating | ||||
Material | Plating | |||
Body | Brass | Tri-alloy | ||
Insulator | PTFE | - | ||
Center conductor | Brass(Male) (Female) | Ag |








All our products can satisfy :
1: Customized Color (Black, Red, Grey, Golded,etc.)
2: Used in IBS/DAS/Public Safety/ Small Cell /Public Network / Private Network
3: Trial order accepted to prove our superior quality
4: OEM/ODM available .
5: Product Lead: delivery within 4 weeks for mass production
6: Unbeatable price to support you win the bid
All our products category :
RF Antenna , RF combiner, Power Splitter , Directional Coupler, Hybrid Coupler, RF Loads, RF Attenuator , Cable Assembly , RF Jumper Cable, RF Coaxial Cable , Cable clamp , etc.
We owe one-stop supply chain capability , you can get the lowest price for your DAS/IBS project .
Customers we served :
HUAWEI, ZTE, ERICSSON and their branch abroad, CHINA MOBILE, CHINA UNICOM, CHINA TELECOM and ROSENBERGER, RSF, etc.
Cooperate Once, Replace Never !
